MCP3421 I2C SOT23-6 delta-sigma ADC Evaluation Module Board For PICkit Serial Analyzer Module

This board works with the PICkit Serial Analyzer.
This boad allows the user to measure the unknown input voltage with a minimum amount of preparation.
Write and read the MCP3421 configuration register bits using the PICkit Serial Analyzer.
Read the ADC conversion results using the PICkit Serial Analyzer.
Many test pads including the SCL and SDA allow to monitor the I2C signals data comunications.
The user can connect the SDA and SCL pins to their own PCB board and evaluate the MCP3421 device performance.
