Name: 2.54mm FC 10/14/16/20/26/30/34/40/50/64 Pin IDC Female Header Socket Connector For 1.27mm Pitch Flat Cable 10P 14P 16P 20P
SKU: 2F7B9BM9ERZR
Availability: InStock

SKU: 2F7B9BM9ERZR

$1.94 – $6.39

3104 Items sold in last week

Pins

Clear

Add to compare

Payment Methods:

Description

Features:
Pitch 2.54mm
Gender: Female
Number of Pins: 10-64P
Connector type: IDC
Type of Row: Double-Row
Applications: use for 1.27mm pitch flat cable:

Specifications:
Current Rating: 3AMP
Operation Temperature: -40°C to +105°C
Contact Resistance: 20mΩ Max.
Insulation Resistance: 1000MΩ Min.
Withstanding Voltage: AC 1000V
Insulator Material: Polyester(UL94V-0)
Standard: PBT
Contact Material: Brass
Contact Plating: Au or Sn over 50 u” Ni
Package Included:
10pcs 2.54mm FC IDC Female Header Socket Connector
